Rockwell Automation 1440-TTC06-00RE XM-362 Temperature Module User Manual
Page 28

Publication GMSI10-UM008D-EN-P - August 2010
20
24
TC 3 (-) / RTD 3 (-)
TC 3 (-)
Negative terminal when channel configured as a
thermocouple input
Constant current return in an RTD configuration
Negative side of the lead wire detection
25
TC 4 (+) / RTD 4 (-)
TC 4 (+)
Positive terminal when channel configured as a
thermocouple input
Negative side of the voltage across the RTD in an RTD
configuration
Positive side of the lead wire detection in a 3-wire RTD
configuration
26
TC 4 (-) / RTD 4 (-)
TC 4 (-)
Negative terminal when channel configured as a
thermocouple input
Constant current return in an RTD configuration
Negative side of the lead wire detection
27
TC 5 (+) / RTD 5 (-)
TC 5 (+)
Positive terminal when channel configured as a
thermocouple input
Negative side of the voltage across the RTD in an RTD
configuration
Positive side of the lead wire detection in a 3-wire RTD
configuration
28
TC 5 (-) / RTD 5 (-)
TC 5 (-)
Negative terminal when channel configured as a
thermocouple input
Constant current return in an RTD configuration
Negative side of the lead wire detection
29
TC 6 (+) / RTD 6 (-)
TC 6 (+)
Positive terminal when channel configured as a
thermocouple input
Negative side of the voltage across the RTD in an RTD
configuration
Positive side of the lead wire detection in a 3-wire RTD
configuration
30
TC 6 (-) / RTD 6 (-)
TC 6 (-)
Negative terminal when channel configured as a
thermocouple input
Constant current return in an RTD configuration
Negative side of the lead wire detection
31
4-20 mA 4 (+)
4-20 mA output 4, positive side
32
4-20 mA 5 (+)
4-20 mA output 5, positive side
33
4-20 mA 6 (+)
4-20 mA output 6, positive side
34
4-20 mA 1 (-)
4-20 mA output 1, negative side
35
4-20 mA 2 (-)
4-20 mA output 2, negative side
36
4-20 mA 3 (-)
4-20 mA output 3, negative side
37
+24 V In
Connection to primary external +24 V power supply, positive
side
38
24 V Common
Connection to external +24 V power supply, negative side
(internally DC-coupled to circuit ground)
39
Reserved
Terminal Block Assignments
Name
No.
XM-361
XM-362
Description
