Publication GMSI10-UM008D-EN-P - August 2010
97
Parameter Object
(Class ID 0F
H
)
The Parameter Object provides the interface to the XM-361 and XM-362
configuration data. There are 38 Parameter Object instances implemented in
the XM-361 and XM-362 modules.
Parameter Object instances 1-22 and 31-36 are implemented to provide an
alternate method of setting the configuration parameters with EPATH or
ENGUNIT data types. And Parameter Object instances 23 and 24 provide an
alternate method of setting the Produced Connection Size and Produced
Connection Path attributes for the Poll Connection because these attributes
can be difficult to get/set directly through the Connection Object.
Class Attributes
Instances
There are 38 instances of this object.
Table C.23 Parameter Object Class Attributes
Attr ID
Access
Rule
Name Data Type Description Semantics
2 Get Max Instance UINT Maximum instance
number of an object in
this class. Total number of parameter
object instances.
8 Get Parameter Class
Descriptor WORD Bits that describe the
parameter. Bit 0 Supports Parameter
Instances
Bit 1 Supports Full Attrib.
Bit 2 Must do non-volatile store
Bit 3 Params in non-volatile
9 Get Config.
Assembly
Instance UINT Set to 0
Table C.24 Parameter Object Instances
Instance
Read
Only
Name Data Type Valid Values Default Value
1 Yes Measurement Unit Channel 1 USINT 0 = Deg C
1 = Deg F 0
2 Yes Measurement Unit Channel 2 USINT 0 = Deg C
1 = Deg F 0
3 Yes Measurement Unit Channel 3 USINT 0 = Deg C
1 = Deg F 0
4 Yes Measurement Unit Channel 4 USINT 0 = Deg C
1 = Deg F 0
