Publication GMSI10-UM008D-EN-P - August 2010
85
Services
1
Attributes can only be set while the device is in Program Mode. See the description of the Device Mode Object
for more information.
DeviceNet Object
(Class ID 03
H
)
The DeviceNet Object is used to provide the configuration and status of a
physical attachment to DeviceNet.
4
Boot Program
Vendor-specific, indicates that the boot program is
running. The Main Application must be corrupt or
missing.
5 - 7
Vendor-specific, not implemented
8
Minor Recoverable
Fault
Set whenever there is a sensor out of range. Also set if
the ambient temperature is measured to be outside of
the module’s operating range.
9
Minor Unrecoverable
Fault
Set when one of the cold junction temperature sensors in
the terminal base is judged to be bad.
10 Major
Recoverable
Fault
Set when the module detects a major problem that the
user may be able to recover from. The Module Status
LED will flash red. An example of this condition is when
the boot program is running.
11
Major Unrecoverable
Fault
Set when there is a module status fault (Module Status
LED is solid red).
12 - 15
Reserved, set to 0
Table C.3 Identity Object Services
Service
Code
Class/Instance Usage
Name
01
h
Instance
Get_Attributes_All
05
h
Instance
Reset
0E
h
Instance
Get_Attribute_Single
10
h
Instance
Set_Attribute_Single
1
Table C.2 Identity Object Status
Bit
Name
Description
