Publication GMSI10-UM008D-EN-P - August 2010
96
Services
1 Attributes can only be set while the device is in Program Mode. See the description of the Device Mode Object
for more information.
113 Get/Set Sensor Type BYTE Specifies the sensor type. 1 = B TC or 100 Ohm Pt 385
2 = C TC or 200 Ohm Pt 385
3 = E TC
4 = J TC
5 = K TC or 100 Ohm Pt 3916
6 = N TC or 200 Ohm Pt 3916
7 = R TC
8 = S TC
9 = T TC or 10 Ohm Cu 427
10 = 120 Ohm Ni 672 (XM-361
only)
11 = 100 Ohm Ni 618 (XM-361
only)
22 = 250 Ohm Pt 392 (XM-361
only)
116 Get/Set Digital Filter UINT Controls the time
constant of the digital
filter. Milliseconds
127 Get/Set Channel ID
(XM-361 only)
CHAR Channel type identifier
(selects between RTD and
TC options in Sensor
Type attribute). B = RTD input
C = TC input
143 Get/Set Sensor Tag STRING2 A descriptive name for the
sensor or channel.
147 Get/Set Data Units ENGUNIT The data units of Value,
Low Engineering, and
High Engineering. Not settable for the XM-361 and
XM-362 modules.
150 Get/Set Rate Value REAL The rate of change of the
analog input value. Data Units per minute
151 Get/Set Rate Filter REAL Controls the time
constant of the rate filter. Seconds
Table C.21 Analog Input Point Object Class Attributes
Attr ID
Access
Rule
Name Data Type Description Semantics
Table C.22 Analog Input Point Object Services
Service
Code
Class/Instance Usage Name Description
0E
h
Class/Instance Get_Attribute_Single Returns the contents of the
specified attribute.
10
h
Instance Set_Attribute_Single Sets the contents of the
specified attribute.
1
