7-6 WebPak 3000 OIM User Guide
Table 7.1 – Possible OIM Responses to “Why is the Drive Not Ready?”
Display Description
DOWNLOAD IN PROGRESS WebPak CS configuration file download
procedure is in progress or the configuration
parameters are being processed.
COAST / DB STOP OPEN The coast/DB stop input (TS 8) is open.
CUSTOMER INTERLOCK OPEN The customer interlock (TS 9) is open.
MEMORY OPERATION IS PROGRESS Non-volatile memory is being restored.
DRIVE IS IN PROCESS OF STOPPING The drive is in the process of stopping.
THERE IS A DRIVE FAULT ( S ) The drive has one or more active faults.
A STOP INPUT IS ACTIVE A keypad stop or the active control source
stop is asserted.
THE DRIVE IS READY The drive is ready to start.
Table 7.2 – Possible OIM Responses to “Why Did the Drive Stop?”
Display Description
JOG WAS RELEASED The jog input from the active control source
was released.
CURRENT LIMIT STOP Current limit stop was selected by STOP MODE
SELECT (P.114).
RAMP STOP Ramp stop was selected by STOP MODE
SELECT (P.114).
COAST / DB STOP Coast/DB stop was selected by STOP MODE
SELECT (P.114).
FAULT STOP Internal fault stop or normal self-tuning stop.
CUSTOMER INTERLOCK OPEN The customer interlock (TS 9) opened.
COAST / DB STOP OPEN The coast/DB stop was asserted (TS 8).
MAIN CONTACTOR IS OPEN The main contactor opened.
DRIVE IS IN PROCESS OF STOPPING The drive is in the process of stopping.
DRIVE IS RUNNING The drive is running.
DRIVE IS JOGGING The drive is jogging.
