Basics of Configuring the Drive Using the OIM 4-3
4.2.2 Using Help in Program Mode
In program mode, you can access help for menus and parameter entry screens. To get
help, press when the menu or parameter entry screen is displayed. When you
have read the help screen, press to return to the previous screen.
If you see ▲ or ▼ on the help screen, there is more text. Press or to display
the additional text.
The Main Menu help screen is shown in figure 4.2.
In a menu, help gives an overview of the menu options. The Drive Reference menu
help is shown in figure 4.3.
In a parameter entry screen, the help screen gives you the parameter name, number,
type, and units of measure. A typical parameter help screen is shown in figure 4.4.
In the help screen shown in figure 4.4:
• The name of the parameter is BASE SPEED .
• The parameter number (code) is P.00017.
• The parameter type is INPUT . The parameter type can also be OUTPUT .
• The save type is RETENTIVE . The save type can also be NON - RETENTIVE .
• The units of measure are RPM . If units of measure do not apply, this line is blank.
For full descriptions of parameters, see the software manual.
Figure 4.2 – Main Menu Help Screen
Figure 4.3 – Example of the Drive Reference Menu Help Screen
Figure 4.4 – Example of a Parameter Help Screen
0(18 +(/3
:HE3DN 0DLQ 0HQX
6HOHFW WKH PHQX LWHP ZLWK 83'2:1 NH\V
DQG WKHQ (17(5 8VH &$1&(/ WR UHWXUQ WR
WKH SUHYLRXV PHQX OHYHO
0(18 +(/3
'ULYH 5HIHUHQFH
'HWHUPLQHV ZKLFK GULYH DQG WULP UHI
VLJQDOV ZLOO EH XVHG KRZ WKH\ DUH WR EH
OLPLWHG VFDOHG DQG FRQGLWLRQHG
3$5$0(7(5 +(/3
%$6( 63((' 3
,1387
5(7(17,9(
530
3UHVV &$1&(/ WR FRQWLQXH
