Rockwell Automation WebPak 3000 User Guide User Manual
Page 36

4-10
WebPak 3000 OIM User Guide
Step 4. Select the action you want to perform. Press
. Depending on the
action you select, you will see:
•
Memory Save:“The current parameter values will be saved to memory.
Continue?”
•
Memory Restore: “The last saved values will be restored. Continue?”
•
Restore Defaults: “The factory default values will be restored. Continue?”
An example of the Memory Save message is shown in figure 4.12.
Step 5. To select
YES
, press
.
Step 6. Press
. You are returned to the Memory Operations menu. Memory
Save, Memory Restore, or Restore Defaults is complete.
4.4.2 Saving Parameter Values When Exiting Program Mode
In program mode, if you press
when you are in a menu or parameter entry
screen and have not yet saved parameter changes, you are prompted to save them.
The prompt is shown in figure 4.13.
Select
YES
and press
. The message shown in figure 4.14 is displayed.
To save the changes and go to monitor mode, select
YES
and press
.
(To go to monitor mode without saving changes, select
NO
and press
on either
of these screens.)
Figure 4.12 – Memory Save Screen
Figure 4.13 – Parameters Have Been Modified Screen
Figure 4.14 – Save Current Parameter Values Screen
