A-2 SP120 AC Drive Installation and Operation
English
Overoad capacity Software: 150% for 60 sec (once in 10 min); Hardware: 220%
Starting torque minimum 100% or more (when torque boost has been set)
Inherent Braking Torque S12-201P4 ...204P0: 100%
S12-205P0 ...207P1: 70%
S12-20010 ...20015: 20%
(approximate; actual values depend on motor characteristics)
DC brake Starting frequency, braking torque, running times are variable
Analog inputs 0 to 10 V, input impedance 10 k
Ω
4 to 20 mA, input impedance 250
Ω
PTC input
Digital inputs 5 programmable level-triggered inputs, 24 V PNP logic, NO or NC contacts
Analog outputs 1 programmable analog output, 0 to 10 V, 1 mA
Accuracy: +5% for frequency, + 20% or current
Digital outputs 2 open collector outputs; 27 VDC, 50 mA
Relay output 1 fault indication relay (change-over contact)
Resistive rating: 2.5 A at 250 VAC; 3 A at 30 VDC
Inductive rating: 0.2 A at 250 VAC; 0.7 A at 30 VDC
Protection functions Overcurrent, overvoltage, undervoltage, electronic motor protection,
overtemperature, ground fault
Other functions 15 preset speeds, PID control, unintentional start protection,
RS422 serial interface, skip frequencies
Ambient temperature -10 to +40
°
C (up to +50
°
C by removing top cover, reducing carrier frequency to
2 kHz, and derating output by 20%)
Relative humidity 20 to 90% relative hmidity, no condensation
Vibration/Shock Vibration: 0.6 G operational / Shock: 10.0 G operational
Max. Installation altitude 1000 m (3300 ft) above sea level
Options Line filter modules
Standards EN 61800-3 EMC guidelines in connection with optional line filter modules in line
with installation guidelines
EN 50178 Low Voltage guideline
CE applies to 230 VAC and 460 VAC units.

Q E T N O C D N I
X 6 6 9 5 D E T SI L

Q E T N O C D N I
X 6 6 9 D E T S IL
UL508C CSA 22.2
(pending)
N223
