3-8 SP120 AC Drive Installation and Operation
English
3.2.2 F Group – Basic Function Parameters
Tunable parameters are indicated with an asterisk ( * ) precediing the parameter
number.
Parameter
Number Parameter Name / Description
Min./Max.
Range Units
d09 Fault Register
Displays the second and third fault. If there are no faults stored in this
register, then --- will be displayed. To view the third fault, press
PROGram. N/A ---
d16 Elapsed Run Time
Displays the elapsed running time of the drive. The elapsed running
time is the displayed value x 10. 0 to 9999 10
hours
Number Parameter Name / Description
Min./ Max.
Range Units
Factory
Default
*F01 Frequency Command
When A01 [
FREQUENCY COMMAND SELECT ] is set to 00
or 01, this parameter will display the commanded
frequency. When A01 is set to 02, this parameter can
be used to change the commanded frequency on the
fly and write the value into A20 - [
INTERNAL
FREQUENCY ]. When a preset frequency is active, this
parameter can be used to program or change the
value of the preset input on the fly while writing the
value into the corresponding parameter (A21 [
PRESET
FREQUENCY 1] to A35 [ PRESET FREQUENCY 15]).
Note: The value is changed in real time and written to
memory without using the Enter key.
This parameter can be changed while motor is
running.
0.0 to
360.0 0.1 Hz N/A
*F02 Accel Time 1
Time for the drive to ramp from 0.0 Hz to A04
[
MAXIMUM FREQUENCY ]
This parameter can be changed while motor is
running.
0.1 to 3000 <1000, 0.1 s
>1000, 1 s 10.0
*F03 Decel Time 1
Time for the drive to ramp from A04 [
MAXIMUM
FREQUENCY ] to 0.0 Hz
This parameter can be changed while motor is
running.
0.1 to 3000 <1000, 0.1 s
>1000, 1 s 10.0
F04 Start Key Direction
Sets the direction of motor rotation when the drive is
set to Start Key mode, which is controlled by A02
[
START COMMAND SELECT ] and digital input setting 31
{OPE}.
Digital inputs (C01-C05) settings 00 {FW} and 01
{RV} determine direction of Start Key.
00 to 02 00=Forward
01=Reverse
02=Control
Terminal 00
