3-20 SP120 AC Drive Installation and Operation
English
Parameter
Number Parameter Name/Description
Min./Max
Range Units
Factory
Default
Digital Inputs 1 – 5 (continued)
C11
Digital Inputs 1-5 Logic
Sets the digital inputs to be NO or NC contacts
Settings: 00=NO contact (active high)
01=NC contact (active open) 00 to 01 Numeric
Value 00
C12 00
C13 01
C14 00
C15 01
Outputs 11, 12, FM, AL0-AL1
C21 Digital Outputs 11-12
Sets the operation of the digital outputs
Settings: 00={RUN} (Motor running above 0.5 Hz)
01={FA1} (At frequency and above 0.5 Hz)
02={FA2} (Above frequency)
03={OL} (Overload alarm)
04={OD} (PID deviation)
05={AL} (Fault)
Refer to control terminal table in chapter 2 for setting
descriptions. 00 to 05 Numeric
Value 01
C22 00
C23 Output FM Select
Sets the operation of the output FM.
Settings: 00={A-F} (Analog Output Frequency)
01={A} (Motor Current)
02={D-F} (Digital Output Frequency)
Refer to control inputs table in chapter 2 for setting
descriptions. 00 to 02 Numeric
Value 00
C31 Digital Output 11-12 Logic
Sets the digital outputs to be NO or NC contacts.
Settings: 00=NO contact (Active high)
01=NC contact (Active open) 00 to 01 Numeric
Value 00
00
C32
C33 Fault Relay AL1 Logic
Sets the fault relay to be either NO or NC contacts.
Settings: 00 = NO contact (active high)
01 = NC contact (active open)
Refer to control inputs table in chapter 2 for setting
descriptions. 00 to 01 Numeric
Value 01
C41 Overload Alarm Threshold
Sets the allowable overload level before digital outputs
11-12 change state when set to 03 {0L}. 0 to 200% of
drive rating 0.01 A 100% of
drive rating
C42 Above Frequency Accel Threshold
Sets the frequency at which digital outputs 11-12
change state when set to 02 {FA2} if the drive is
accelerating. 0.0 to 360.0 0.1 Hz 0.0
C43 Above Frequency Decel Threshold
Sets the frequency at which digital outputs 11-12
change state when set to 02 {FA2} if the drive is
decelerating. 0.0 to 360.0 0.1 Hz 0.0
C44 PID Deviation Threshold
Sets the allowable PID Loop error before digital outputs
11-12 change state when set to 04 {OD}. 0.0 to 100% +/- 0.1% +/-3.0
