English – Rockwell Automation SP120 ACDrive 115VAC, 1Ph, 230VAC, 1Ph/3Ph, 1/4-5.0HP User Manual
Page 45
Parameters and Programming
3-15
English
Parameter
Number
Parameter Name/ Description
Min./Max
Range
Units
Factory
Default
Second Acceleration/Deceleration Ramp
*A92
Accel Time 2
Time for the drive to ramp from 0.0 Hz to A04 [
MAXIMUM
FREQUENCY
]. A94 [
ACCEL
/
DECEL
2
SELECT
] is used to
determine when active.
This parameter can be changed while motor is running.
0.1 to 3000
<1000, 0.1 s
>1000, 1 s
15.0
*A93
Decel Time 2
Sets the time for the drive to ramp from A04 [
MAXIMUM
FREQUENCY
] to 0.0 Hz. A94 [
ACCEL
/
DECEL
2
SELECT
] is
used to determine when active.
This parameter can be changed while motor is running.
0.1 to 3000
<1000, 0.1 s
>1000, 1 s
15.0
A94
Accel / Decel 2 Select
Used to determine when the A92 [
ACCEL
TIME
2] and
A93 [
DECEL
TIME
2] are used.
Settings: 00=Digital inputs (C01-C05) set to 09{2CH}
01=Automatic if frequency programmed in
A95 [
ACCEL
2
START
FREQUENCY
]/
A96 [
DECEL
2
START
FREQUENCY
] is reached.
00 to 01
Numeric
Value
00
A95
Accel 2 Start Frequency
Sets the frequency at which A92 [
ACCEL
TIME
2] will take
effect if A94 [
ACCEL
/
DECEL
2
SELECT
] is set to 01.
0.0 to 360.0
0.1 Hz
30.0
A96
Decel 2 Start Frequency
Sets the frequency at which A93 [
DECEL
TIME
2] will take
effect if A94 [
ACCEL
/
DECEL
2
SELECT
] is set to 01.
0.0 to 360.0
0.1 Hz
30.0
A97
Accel Curve
Selects the type of acceleration curve.
Settings: 00=Linear
01=S-curve
00 to 01
Numeric
Value
00
A98
Decel Curve
Selects the type of deceleration curve.
Settings: 00=Linear
01=S-curve
00 to 01
Numeric
Value
00
