English – Rockwell Automation SP120 ACDrive 115VAC, 1Ph, 230VAC, 1Ph/3Ph, 1/4-5.0HP User Manual
Page 51
Parameters and Programming
3-21
English
Parameter
Number
Parameter Name/Description
Min./Max
Range
Units
Factory
Default
Communications
C70
Communication Command Select
Selects the source of the communication command.
Settings: 02 = Remote Operator
03 = RS422
02 to 03
Numeric
Value
02
C71
Baud Rate
Selects the Baud Rate for RS422 communication.
Settings: 04 = 4800 bps
05 = 9600 bps
06 = 19200 bps
04 to 06
Numeric
Value
04
C72
Drive Address
Sets the drive node address on the RS422 network.
01 to 32
N/A
01
C79
Communication Error Select
Selects the drives operation when a communication
error (E60) occurs.
Settings: 00 = Fault
01 = No Fault and continue operation
00 to 01
Numeric
Value
00
C91
Debug Mode
Used by Rockwell Automation field service personnel.
00 to 01
Numeric
Value
00
C92 - C95 [Reserved]
Reserved for future use. Do not change.
00 to 01
Numeric
Value
00
!
ATTENTION: If C91 [
DEBUG
MODE
] is set
to 01, parameters C92 to C95 are
enabled. Do not change parameters C91
to C95. Failure to observe this precaution
could result in personal injury
