Page 19

Installing and Wiring the Drive

2-5

English

2.4.3 Branch Circuit Protection Devices

The following table shows the minimum recommended values for the branch circuit
protection devices:

2.4.4 Input Power Conditioning

The drive is suitable for connection to input power within the rated voltage of the drive
(see specifications). The power factor of the input power supply must not exceed .99.
Compensation systems must ensure that overcompensation does not occur at any
time.

If the drive must be installed in any of the following conditions, a 3% impedance input
line reactor must be used:

•

line has intermittent noise spikes in excess of 2000 V

•

frequent voltage dips occur

•

the drive is operated on a generator

•

line has power factor correction capacitors

•

several drives are linked via a short common power supply bus bar

Table 2.2 – Branch Circuit Protection

Fuse Rating (Class J)

Circuit Breaker Type

Model

Single-Phase

Three-Phase

Single-Phase

Three-Phase

S12-101P4LU

10A

N/A

140M-D8N-C10

N/A

S12-102P6LU

15 A

N/A

140M-D8N-C16

N/A

S12-104P0LU

20 A

N/A

140M-D8N-C25

N/A

S12-201P4LU

10 A

140M-D8N-C10

140M-D8N-B40

S12-202P6LU

10 A

140M-D8N-C10

140M-D8N-B63

S12-203P0LU

10 A

140M-D8N-C10

140M-D8N-B63

S12-204P0LU

15 A

140M-D8N-C16

140M-D8N-C10

S12-205P0LU

15 A

140M-D8N-C16

140M-D8N-C10

S12-207P1LU

20 A

15 A

140M-D8N-C16

S12-20010LU

30 A

20 A

140M-D8N-C25

140M-D8N-C16

S12-20015LU

N/A

30 A

N/A

140M-D8N-C25

S12-401P5LU

N/A

3 A

N/A

140M-D8N-B25

S12-402P5LU

N/A

6 A

N/A

140M-D8N-B40

S12-403P8LU

N/A

10 A

N/A

140M-D8N-B63

S12-405P5LU

N/A

10 A

N/A

140M-D8N-C10

S12-408P6LU

N/A

15 A

N/A

140M-D8N-C16
