20

Rockwell Automation Publication 2711P-UM006C-EN-P - April 2013

Chapter 1

Overview

400/600 Terminal Selections

The table shows the catalog number breakdown for the 400 and 600 terminals.

Bulletin

Input Type

Display Size

Display Type

Communication

Power

Operating System

|

|

|

|

|

|

|

2711P-

K = Keypad

4= 3.5 in.

C = Color

5 = RS-232, USB

A = AC

8 = Windows CE 6.0

B = Keypad and Touch

6 = 5.7 in.

M = Grayscale

20 = Ethernet, RS-232, USB

D = DC

9 = Windows CE 6.0 with extended features

T = Touch

Table 10 - PanelView Plus 6 - 400 Terminals without Extended Features

Cat. Nos.

Display

Communication Ports

USB Ports

Input

Power

Memory (MB)

(1)

Keypad

Keypad and Touch

Size

Type

RS-232

Ethernet

Host

Device

RAM

Nonvolatile

2711P-K4M5A8

3.5-in.

Grayscale

AC

256

512

2711P-K4M5D8

DC

256

512

2711P-K4M20A8

AC

256

512

2711P-K4M20D8

DC

256

512

2711P-K4C5A8

2711P-B4C5A8

3.5-in.

Color

AC

256

512

2711P-K4C5D8

2711P-B4C5D8

DC

256

512

2711P-K4C20A8

2711P-B4C20A8

AC

256

512

2711P-K4C20D8

2711P-B4C20D8

DC

256

512

(1) The terminal s support FactoryTalk View Machine Edition software, version 6.10 or later, and the Windows CE 6.0 operating system.

Table 11 - PanelView Plus 6 - 600 Terminals without Extended Features

Cat. Nos.

Display

Communication Ports

USB Ports

Input

Power

Memory (MB)

(1)

Keypad

Touch

Keypad and Touch

Size

Type

RS-232

Ethernet

Host

Device

RAM

Nonvolatile

2711P-K6M5A8

2711P-T6M5A8

2711P-B6M5A8

5.7-in.

Grayscale

AC

256 512

2711P-K6M5D8

2711P-T6M5D8

2711P-B6M5D8

DC

256

512

2711P-K6M20A8

2711P-T6M20A8

2711P-B6M20A8

AC

256

512

2711P-K6M20D8

2711P-T6M20D8

2711P-B6M20D8

DC

256

512

2711P-K6C5A8

2711P-T6C5A8

2711P-B6C5A8

5.7-in.

Color

AC

256

512

2711P-K6C5D8

2711P-T6C5D8

2711P-B6C5D8

DC

256

512

2711P-K6C20A8

2711P-T6C20A8

2711P-B6C20A8

AC

256

512

2711P-K6C20D8

2711P-T6C20D8

2711P-B6C20D8

DC

256

512

(1) The terminals support FactoryTalk View Machine Edition software, version 6.10 or later, and the Windows CE 6.0 operating system.

Table 12 - PanelView Plus 6 - 600 Terminals with Extended Features

Cat. Nos.

Display

Communication

USB Ports

Input

Power

Memory (MB)

(1)

Keypad

Touch

Keypad and Touch

Size

Type

RS-232

Ethernet

Host

Device

RAM

Nonvolatile

2711P-K6C5A9

2711P-T6C5A9

2711P-B6C5A9

5.7-in.

Color

AC

256

512

2711P-K6C5D9

2711P-T6C5D9

2711P-B6C5D9

DC

256

512

2711P-K6C20A9

2711P-T6C20A9

2711P-B6C20A9

AC

256

512

2711P-K6C20D9

2711P-T6C20D9

2711P-B6C20D9

DC

256

512

(1) The terminals support FactoryTalk View Machine Edition software, version 6.10 or later, and the Windows CE 6.0 operating system with extended features and file viewers.
