Chapter
4
4-1
Installing Your Programmable Controller
This chapter discusses the location and methods of installing your
processor. When you have finished, you should be able to:
determine where to locate your processor system
install your processor system
Table 4.A lists the hardware needed to install your processor system.
Table 4.A
Hardware for Your Processor System
AllenĆBradley Hardware Catalog Number
I/O chassis 1771ĆA1B, ĆA2B, ĆA3B, ĆA3B1, ĆA4B
I/O modules 1771 product line
Industrial terminal 1770ĆT3 series C
Power supplies 1771ĆP3, ĆP4, ĆP5, ĆP7
Emergency stop 800 product line switches
Master control relay 700 product line
Disconnects 1494 product line
Suppression devices 599ĆK04, 700ĆN24, 1401ĆN10
The quantity of the hardware you need depends on your application.
Consult your local Allen-Bradley sales engineer or distributor for more
information concerning these items.
In addition to our hardware, we recommend:
a metal enclosure to protect your processor from electromagnetic
interference (EMI) noise and airborne contaminants
enclosure backpanel
power supplies for I/O devices
6.35 mm (0.25 inch) bolts
power cable for ac input power
electrical tape or shrink tubing
tie wraps for wires
Chapter Objectives
Related Hardware
