Data Transfer File Instruction
Chapter 19
19-10
Proceed by loading each position of file A with following data:
Position 003 0879
Position 004 0162
Position 005 1982
Position 006 9715
Position 007 5761
Important: You do not have to enter data in each position. You can skip
position numbers.
All the data for file A is entered.
The File-to-File Move instruction rung is displayed.
The word SEARCH appears in the lower left corner of the industrial
terminal screen.
Puts the processor in the run/program mode.
The word DISPLAY appears in the lower left corner of the industrial
terminal screen.
1
HEXDECIMAL DATA MONITOR
FILE TO FILE MOVE
POSITION: 001 COUNTER ADDR:
FILE A:
200
400Ć406
FILE LENGTH:
FILE R:
007
500Ć 506
POSITION FILE A DATA FILE R DATA
001
002
003
004
005
006
007
1257
0721
0879
0162
1982
9715
5761
1257
0721
0879
0162
1982
9715
5761
Notice that the data in file A transferred to file R.
Do not clear your processor memory. We will use this rung to edit the file.
