Sequencer
Chapter 21
21-23
Load your data from Figure 21.6 exactly as you did in the Sequence Input
and Output instructions.
To display your rung.
CANCEL
COMMAND
Your Sequencer Load instruction should look like this.
BINARY DATA MONITOR
SEQUENCER OUTPUT
COUNTER ADDR: 056
STEP: 008
SEQUENCER LENGTH: 012
FILE: 510- 567
LOAD ADDR: 110
DATA: 00000000 00000000
STEP
WORD 1
001
002
003
004
005
006
007
008
009
010
011
012
00000010
00000000
00000000
10000010
01000000
00000000
10000000
00000000
00000000
00000001
00100000
00000000
10000000
10001000
00100100
00001000
00010000
00000001
00100000
10000000
10000000
00010000
00000000
00000000
