Data Transfer File Instruction
Chapter 19
19-16
Here is an explanation of each value:
This Value: Stores This:
Counter address Address of the instruction's file position in the accumulated
value area of the data table.
Position Current word being operated upon (accumulated value of
the counter).
File Length Number of words in file (preset value of the counter).
File A Starting address of the source file.
Word Address Address of the destination (output) word outside of the file.
Once you establish your file data, you’ll want to edit, load, or monitor your
file data. To perform these functions the processor has a data monitor
mode (Figure 19.3). Use one of these displays:
binary display (Display 0) lets you manipulate one bit at a time by
displaying each word using binary digits.
hexadecimal display (Display 1) lets you manipulate 4 digits which
represents word values.
ASCII display (Display 2) converts your four digits to the ASCII code.
Data Monitor Display
