Hardware Features
Chapter 3
3-10
8.
After a short while the following display appears.
DIAGNOSTICS PASSED
MODE SELECTION
KEYBOARD MODULE 1770-FD C SERIES B/H
MODE:
INSERT
KEYTOP OVERLAY:
FOR USE WITH
THE FOLLOWING
PROCESSORS:
10 = PLC
11 = PLC-2
1770-KBA
PLC
MINI-PLC-2,PLC-2
PLC-2/02
PLC-2/05,PLC-2/15
PLC-2/16,PLC-2/17
PLC-2/20(PL1)
PLC-2/20(LP2)
PLC-2/30
12 = ALPHANUMERIC
SELECT DESIRED MODE?
1770-KAA
1770-KCB
9.
Select the PLC-2 mode by pressing [1] [1] on the 1771-T3 terminal.
Industrial Terminal Keyboard
The detachable keyboard houses PROMs, a sealed touchpad, and a
keytop overlay.
There are three keytop overlays:
PLC-2 family processor –– for use with any PLC-2 family processor.
PLC processor –– for use with any PLC family processor.
Alphanumeric –– for alphanumeric characters and graphic
characters generation.
Key Symbols –– There are no numbered keys greater than 9. To display
numbers greater than 9 press the individual keys. For example:
To display:
10
234
Press individually:
[1][0]
[2][3][4]
