Rockwell Automation 1732E-IR4IM12R ArmorBlock Dual-Port EtherNet/IP 4-Point Thermocouple and RTD User Manual
Page 48
40
Rockwell Automation Publication 1732E-UM004A-EN-E - July 2012
Chapter 4 Configurable Features for the Thermocouple and RTD Input Modules
1732E-IT4IM12R – Configuration Data Structure for Thermocouple Input
Configuration
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
4
Cold Junction Mode
(1)
5…7
Reserved (Ignore)
8…9
Channel 0 Low Engineering
10…11
Channel 0 High Engineering
12
Channel 0 Disable Alarms
13
Channel 0 Enable Alarm Latch
14
Channel 0 Notch Filter
15
Channel 0 Thermocouple Type
16…17
Channel 0 Digital Filter
18…19
Channel 0 Low Alarm
20…21
Channel 0 High Alarm
22…23
Channel 0 Low Low Alarm
24…25
Channel 0 High High Alarm
26
Channel 0 Temperature Units
27
Channel 0 Cold Junction Compensation Enable
28…29
Channel 0 Cold Junction Compensation Offset
30…31
Reserved (Ignore)
32…33
Channel 1 Low Engineering
34…35
Channel 1 High Engineering
36
Channel 1 Disable Alarms
37
Channel 1 Enable Alarm Latch
38
Channel 1 Notch Filter
39
Channel 1 Thermocouple Type
40…41
Channel 1 Digital Filter
42…43
Channel 1 Low Alarm
44…45
Channel 1 High Alarm
46…47
Channel 1 Low Low Alarm
48…49
Channel 1 High High Alarm
50
Channel 1 Temperature Units
51
Channel 1 Cold Junction Compensation Enable
52…53
Channel 1 Cold Junction Compensation Offset
54…55
Reserved (Ignore)
56…57
Channel 2 Low Engineering
58…59
Channel 2 High Engineering
60
Channel 2 Disable Alarms
61
Channel 2 Enable Alarm Latch
