192 Rockwell Automation Publication 1756-UM540A-EN-P - May 2014
Appendix A Isolated Analog I/O Module Tag Definitions
Ch[x].ProgToFaultEn BOOL Determines channel action if a connection faults while
the module is in a safe state for Program mode.
The channel can remain in the safe state for Program
mode or transition to a safe state for Fault mode.
If the channel remains in safe state for Program mode, the
C.Ch[x].FinalFaultState tag value is ignored. • 0 = Channel remains in the safe
state for Program mode
• 1 = Channel transitions to the
safe state for the Fault mode
Ch[x].ClampingDisable BOOL Disables Clamping on the channel. • 0 = Clamping enabled
• 1 = Clamping disabled (default)
Ch[x].RampInRun BOOL Enables Output Ramping when the module is in
Run mode.
Output changes during Run mode are limited to the
C.Ch[x].MaxRampRate tag value. • 0 = Ramping disabled (default)
• 1 = Ramping enabled in
Run mode
Ch[x].RampToProg BOOL Enables Output Ramping when the channel is
transitioning to Program mode.
Output changesduring Program mode are limited to the
C.Ch[x].MaxRampRate tag value. • 0 = Ramping disabled (default)
• 1 = Ramping enabled to
Program mode state
Ch[x].RampToFault BOOL Enables Output Ramping when the channel is
transitioning to Fault mode.
Output changes during Fault mode are limited to the
C.Ch[x].MaxRampRate tag value. • 0 = Ramping disabled (default)
• 1 = Ramping enabled to Fault
mode state
Ch[x].Disable BOOL Disables the channel. • 0 = Channel enabled (default)
• 1 = Channel disabled
Ch[x].FaultValueStateDuration SINT Determines the length of time the C.Ch[x].FaultValue tag
value is held prior to the C.Ch[x].FaultFinalState being
applied. • 0 = Hold forever (default)
• Any of the following:
– 1, 2, 5, or 10 seconds
Ch[x].OutputRange SINT Channel’s operating range. 0 = -10…10V
1 = 0…20 mA (default)
2 = 0…5V
3 = 0…10V
Ch[x].MaxRampRate REAL Maximum rate at which the channel can transition to in
Engineering Units/Second.
This tag is used only if at least one of the following tags
is enabled:
• C.Ch[x].RampInRun
• C.Ch[x].RampToFault
• C.Ch[x].RampToProgram Any value > 0.0
1,000,000.00 = default
Ch[x].FaultValue REAL Value to which the channel changes if the following
events exist:
• Connection is lost
• C.Ch[x].FaultMode tag is enabled Any
0.0 = default
Table 26 - 1756-OF8I Module - Configuration Tags
Tag Name Size Definition Valid Values
