PowerFlex 700S Adjustable Frequency AC Drive - Phase II Control
Catalog Number Explanation, Continued
Feedback
Code
Option
N
Standard (Incremental Encoder)
A
Resolver
B
Stegmann Hi-Resolution Encoder
C
Multi-Device Interface
E
2nd Encoder
S
Safe-Off (w/2nd Encoder)
Expanded cassette required.
One encoder interface included with base drive.
m
Additional Config.
Code
Description
E
Phase II Control
K
Phase II DriveLogix5730
L
Phase II DriveLogix5730
w/EtherNet/IP
This is an embedded EtherNet/IP option that is
only available with DriveLogix5730.
T
Stegmann Hi-Res Enc. (w/2nd Encoder)
U
Stegmann Hi-Res Enc. (w/Safe-Off)
Documentation
Code
Documents
N
No Documentation
g
Brake
Code
w/Brake IGBT
‡
s
e
Y
Y
o
N
N
‡
Brake IGBT is standard on Frames 1…3 and
optional on Frames 4…9 ONLY.
h
Brake Resistor
Code
w/Resistor
Y
Yes
o
N
N
Not available for Frame 3 drives or larger.
English Manual
E
j
Comm Slot
Code
Version
N
None
C
DPI ControlNet (Coax)
D
DPI DeviceNet
E
DPI EtherNet/IP
1
DriveLogix ControlNet (Coax)
2
DriveLogix ControlNet Redundant
(Coax)
3
DriveLogix ControlNet (Fiber)
4
DriveLogix ControlNet Redundant
(Fiber)
5
DriveLogix DeviceNet (Open Conn.)
6
DriveLogix EtherNet/IP
i
Emission
Code
CE Filter
♣
CM Choke
A
♣
Note: CE Certification testing has not been
performed on 600V class drives Frames 1…4.
Yes
Yes
du/dt Filter
No
k
Control Options
Code
Cassette
A
Phase II Contol available only.
B
C
D
G
H
Logix Expansion
Synchlink
No
Expanded
Slim
No
No
Expanded
Yes
Yes
Expanded
No
Yes
Expanded
Yes
No
N/A
Slim
Yes
N/A
Frames 1...9 only.
