Figure 7 - frame 6 – Rockwell Automation 20D PowerFlex 700S Phase II Drive Frames 1...6 Installation Instructions User Manual
Page 21
Rockwell Automation Publication 20D-IN024C-EN-P - July 2013
21
PowerFlex 700S Adjustable Frequency AC Drive - Phase II Control
Figure 7 - Frame 6
116.6
(4.59)
148.5
(5.85)
222.3
(8.75)
242.0
(9.53)
219.0
(8.62)
185.4
(7.30)
151.8
(5.98)
52.1 (2.05)
69.1 (2.72)
130.1 (5.12)
280.1 (11.03)
330.1 (13.00)
230.1 (9.06)
47.1 (1.85)
45.6 (1.80)
56.2 (2.21)
Removable Junction Box
22.2 (0.87) Dia.
4 Places
62.7 (2.47) Dia.
3 Places
34.9 (1.37) Dia.
3 Places
E
13.5
(0.53)
126.3
(4.97)
8.5
(0.33)
B
Lifting Holes
4 Places
12.7 (0.50) Dia.
D
C
A
360.6 (14.20)
Detail
18.0 (0.71)
8.5 (0.33)
49.6
(1.95)
Detail
Old Style Junction Box
New Style Junction Box
Dimensions are in millimeters and (inches)
Frame
(1)
(1) Refer to Drive Rating to Frame Size Cross References on page
for frame information.
Slim Cassette
A (Max)
Expanded Cassette
AA
B
(2)
(2) Junction Box can be removed if drive is mounted in a cabinet.
C (Max)
D
E
6
403.9 (15.90)
435.8 (17.16)
850.0 (33.46)
275.5 (10.85)
300.0 (11.81)
825.0 (32.48)
