Rockwell Automation Publication 20D-IN024C-EN-P - July 2013 71
PowerFlex 700S Adjustable Frequency AC Drive - Phase II Control
Allen-Bradley servo motors may be ordered with factory installed resolvers. The
list of factory installed resolvers below are supported by the 700S Resolver
Feedback Option card.
Recommended Cable for the Resolver Feedback Card
Rockwell Automation strongly recommends the use of Reliance Electric 417900-
207CG or Belden 9730 cable for installation, or an equivalent cable that meets
these specifications:
• Three twisted pairs, 80° C, 300V
• Chrome FPR jacket, plenum rated
• Conductor size: 18 AWG
• Twists per inch: 2 or 3 twists per inch of wire lay per pair
• Capacitance per pair: not to exceed 30 pF per foot +/- 0.3 pF as read on a
GEN_RAD model 1658 RLC Digibridge or equivalent
• Capacitance difference pair-to-pair: not to exceed 0.6 pF per foot as read
on a GEN_RAD Model 1658 RLC Digibridge or equivalent
• Resistance per 1000 feet: 17.15Ω +/- 10%
• Inductance per 1000 feet: 0.13 mH +/- 10% as read on a GEN_RAD
model 1658 RLC Digibridge or equivalent
• Insulation thickness: 0.008 in.
• Conductor stranding 16/30
• Jacket thickness: 0.018 in.
Motor / Resolver Type Compatible Parameter 277
[Reslvr0 Type Sel]
Configuration
Notes
1326 AB 230V Primary Resolver No Not Supported Receiver type resolver - not supported
1326 AB 460V Primary Resolver Yes 9 - 1326Ax 460v Transmitter type resolver - supported
1326 AB 460V Secondary Resolver Yes 13 - Reserved Secondary resolver is geared to motor -
not intended for motor speed / position
feedback
Transmitter type resolver - supported
1326AD 230V Rare Earth Primary
Resolver No Not Supported Receiver type resolver - not supported
1326AH 460V Explosion Proof Motor
Primary Resolver Yes 9 - 1326Ax 460v Transmitter type resolver - supported
1326AH 460V Explosion Proof Motor
Secondary Resolver Yes N/A Secondary resolver is geared to motor -
not intended for motor speed / position
feedback
Transmitter type resolver - supported
1326AS 460V Rare Earth Primary
Resolver Yes 9 - 1326Ax 460v Transmitter type resolver - supported
MPL 460V Primary Resolver Yes 4 - MPL 460v Transmitter type resolver - supported
