SDC E5 Series Access Control System User Manual
Page 23
SYSTEM MONITORING (AUDIT TRAIL)
Each reader stores every transaction for future uploading to the PC. This data may be retrieved
in a batch or in a real-time manner. Real-time transaction monitoring requires that this program
run at all times.
Batch Collection
Real Time Monitoring
Select Monitor
Select Collect Transactions in Batch (3-1)
Select the reader(s) from the window on the
left, then select Start
. The number of
transactions collected will appear in the
window to the right.
Select Monitor
Select Real Time Monitoring (3-2)
Select the reader(s) from the window on the
left, then select Start
. Transactions will
appear in the window to the right. The reader
polling interval may be changed by adjusting
the slider at the bottom of the screen. Select
Break
to stop the polling.
P:\Installation Instructions\Access Controls\Inst-E5\INST-E5.vsd Rev C 03-13 Page: 20
