Important – MacDon R85 Rotary Disc 16 Foot Pull-Type User Manual
Page 174
IMPORTANT
Blades should be replaced in pairs, otherwise
the disc may be unbalanced and damage
the cutterbar.
IMPORTANT
The cutter blades have cutting edges on
both edges so that the blade can be turned
over and reused.
The twist in each blade
determines if its cutting direction is clockwise
or counterclockwise.
Figure 8.41: Counterclockwise disc rotation
direction
Figure 8.42: Clockwise disc rotation direction
169456
164
Rev. D
