MacDon R85 Rotary Disc 16 Foot Pull-Type User Manual
Page 120
OPERATING THE MOWER CONDITIONER
18. Remove nuts (A) from studs in storage compartment.
19. Secure feed plates (B) to side of compartment with
nuts (A).
Figure 7.42
20. Reinstall cover (B) with bolts (A).
Figure 7.43
169456
110
Rev. D
