SECTION 6 OPERATION

169000 / 169040

50

Revision E

NOTE

The hydraulic hoses do not need to be
attached to the tractor for towing.

Ensure they are securely stored on the
APT.

NOTE

The PTO does not need to be attached
for towing purposes. If not attached,
lower hook (A), store driveline on hook,
and remove forward half (B) of driveline.
Store forward half in cab for transport.

b. Ensure that APT safety chain is properly

attached to towing vehicle. Provide only enough
slack in chain to permit turning.

c. Check local laws for width regulations and

lighting or marking requirements before
transporting on roads.

d. Do

not exceed 20 mph (32 km/h).

6.8.2.2

Transporting With a Truck

CAUTION

Do not tow with a vehicle weighing less than
7500 lb (3400 kg). Ensure that the capacity
of the towing vehicle is sufficient to maintain
control.

If the mower conditioner is in Transport mode,
proceed as follows. Otherwise, see Section
6.8.2.3 Preparing Mower Conditioner for
Transport.

a. Store hydraulic hoses on the APT as shown

opposite.

b. Lower hook (A), and place driveline in hook.

c. Remove the forward half (B) of driveline, and

store in truck for transport.

d. Position towing adapter (C) on APT, and secure

with pins (D).

e. Attach mower conditioner to truck.

f. Remove jack from working position, and store

on APT. Secure with pin.

g. Wrap safety chain around APT, and attach to

truck frame (E).

h. Connect electrical harness (F).

i. Check local laws for width regulations and

lighting or marking requirements before
transporting on roads.

j. Do

not exceed 20 mph (32 km/h).

E

F

A

B

C

D
