SECTION 7 MAINTENANCE AND SERVICING
169000 / 169040
178
Revision E
7.18.2 Pull-Type Mower Conditioner
7.18.2.1 Break-In Inspection: Pull-Type
HOURS ITEM CHECK REFERENCE
1
Wheel Bolts
Torque
120 ft·lbf (160 N·m) Section 7.14.1
Steering Cylinder Clevis and
Stroke Control
52 ft·lbf (72 N·m)
5, 25, 50
Auger Drive Belt
Tension
Sections 7.11.3 and 7.11.4
Reel Drive Belt Section 7.9.2
Sickle Drive Belt Sections 7.8.9 and 7.8.10
5 Hardware Torque Section 7.3.1
10
Auger Drive Chain Tension/
Lubricate
Sections 7.11.1 and 7.11.2
Reel Drive Chain Section 7.9.1
Sickle Drive Box Mounting Bolts Torque 200 ft·lbf (270 N·m) Section 7.8.13
7.18.2.2 Interval Maintenance: Pull-Type
INTERVAL SERVICE
FIRST USE Refer To Section 7.18.2.1 Break-In Inspection: Pull-Type
100 HOURS OR
ANNUALLY *
1. Check Conditioner Drive Gearbox Lubricant
Level.
2. Check Sickle Drive Box Lubricant Level.
3. Check Sickle Drive Box Mounting Bolt
Torques.
4. Check Wheel Bolt Torques.
5. Grease Wheel Hub Bearings.
6. Change Hydraulic Oil Filter (First 100
Hours Only; Every 250 Hours After).
END OF SEASON Refer To Section 6.19 STORAGE.
10 HOURS OR
DAILY
1. Check Hydraulic Oil Level.
2. Check Hydraulic Hoses And Lines For Leaks.
3. Oil Sickle (Except In Sandy Conditions).
4. Check Sickle Sections, Guards, and Hold
Downs.
5. Oil Reel Drive Chain.
6. Oil Auger Drive Chain.
7. Check Tire Pressure.
8. Check Sickle Drive Box Bolt Torque (First
10 Hours Only; Every 100 Hours After).
25 HOURS 1. Grease Sickle Head.
50 HOURS
1. Grease APT Pivot.
2. Grease Reel Shaft Bearings.
3. Grease Auger and Jack-Shaft Bearings.
4. Grease Conditioner Drivelines.
5. Grease Conditioner Shaft Bearings.
6. Grease Roll Pivots Bearing.
7. Grease Frame-To-Header Pivots. 8. Grease Lower Float Link Bushings.
9. Grease Gauge Roller Bearings.
10. Change Sickle Drive Box Lubricant. (First
50 Hours Only; Every 1000 Hours After).
11. Change Conditioner Drive Gearbox
Lubricant (First 50 Hours Only; Every 1000
Hours After).
250 HOURS Change Hydraulic Oil Filter.
500 HOURS OR
3 YEARS
Change Hydraulic Oil.
1000 HOURS OR
3 YEARS
1. Change Sickle Drive Box Lubricant.
2. Change Conditioner Drive Gearbox
Lubricant.
* IT IS RECOMMENDED THAT ANNUAL MAINTENANCE BE DONE PRIOR TO START OF OPERATING SEASON.
