SECTION 5 SPECIFICATIONS
169000 / 169040
19
Revision E
5 SPECIFICATIONS
5.1 PULL-TYPE HEADERS
HEADER SIZE 14 FT 16 FT 18 FT
HEADER MODEL A30-S A30-D A30-S A30-D A30-D
FRAME and STRUCTURE
Width
16 ft-3 in.
(4953 mm)
n/a 17 ft-9 in. (5410 mm)
19 ft-3 in.
(5867 mm)
Length
Transport 26 ft-7 in. (8130 mm)
Field 26 ft-7 in. (8130 mm)
Height
Transport 86 in. (2184 mm)
Field 86 in. (2184 mm)
Approximate Weight [lb (kg)]
7200
(3269)
n/a
7400
(3360)
8000
(3632)
8200
(3723)
Carrier Pull-Type
Lighting Two Amber and Two Red Transport Lights
Spare Knife Storage Frame Tube Lean Bar Frame Tube Lean Bar
Reversing Wrench /
Guard Straightening Tool
Stored Inside LH Endsheet
Manual Storage Frame Mounted Case
WHEELS
Tires 31 x 13.5 - 15 NHS 8 Ply Terra-Rib
Tread Width 150 in. (3810 mm)
Pressure 30 psi (207 kPa)
CUTTERBAR
Effective Cutting Width
14 ft-9 in.
(4496 mm)
16 ft-3 in.
(4953 mm)
17 ft-9 in.
(5410 mm)
Cutting Height 4 in. (100 mm) Below Ground to 21 in. (533 mm) Above Ground
Guard Angle Adjustment 8–16°
MAIN DRIVE
Tractor PTO Driven
Gear Pump
1000 rpm PTO 2.01 cu. in. (33 cc) with 3:1 Ratio Gearbox
HEADER DRIVE
Hydraulic M44 (44 cc) Motor To Gearbox
SICKLE
Drive Type
Type Belt Driven Heavy Duty (MD) Sickle Drive Box (Enclosed Oil Bath)
Qty One Two One Two
Sickle Speed
(Strokes Per Minute)
No Load 1970 1980 1970 1980
Load 1510 1910
Stroke 3 in. (76 mm)
Sections Bolted Over-Serrated, 9 Serrations/Inch.
Guards Forged and Double Heat-Treated
