SECTION 5 SPECIFICATIONS
169000 / 169040
22
Revision E
SELF-PROPELLED HEADERS (cont’d)
HEADER SIZE 14 FT 16 FT 18 FT
HEADER MODEL A30-S A40-D A30-S A40-D A30-D A40-D
REEL
Drive
Hydraulic Direct Mounted
Motor
---
14.2 in 3
(232 cc)
/rev
---
14.2 in 3
(232 cc)
/rev
---
14.2 in 3
(232 cc)
/rev
Mechanical From Auger
2
Belts/Chain
Final Drive
---
2
Belts/Chain
Final Drive
---
2
Belts/Chain
Final Drive
---
Type
5-Bat 6-Bat 5-Bat 6-Bat 5-Bat 6-Bat
(6-Bat Opt) (7 Opt) (6 Opt) (7 Opt) (6 Opt) (7 Opt)
Tines Steel: 0.25 in. (6 mm) Dia.
Tine Bar
Bearings Replaceable
Polyethylene
Greasable
Ball
Replaceable
Polyethylene
Greasable
Ball
Replaceable
Polyethylene
Greasable
Ball
Radius (to tine tip) 22 in. (540 mm)
Maximum
Speed
(rpm)
22T Sprocket
22T Auger 77
15–85*
77
15–85*
73
15–85*
19T Auger
67 67 69
19T Sprocket
22T Auger
19T Auger 58 58 66
CONDITIONER
Drive Hydraulic M44 (44cc) Motor To Enclosed Oil-Bath Gearbox
Roll Type Intermeshing Steel Bars
Roll Diameter
Bars 9.17 in. (233 mm) O.D.
Tube 6.63 in. (168 mm) O.D.
Roll Length 102 in. (2590 mm)
Roll Speed (rpm) 810 601–810 810 601–810 810 601–810
Unplugging Assist Reversing Flow To Hydraulic Motors
Forming Shields
Windrower Mounted Side Deflector System For
36 in. (915 mm) to 100 in. (2540 mm) Swath Width
OPERATING SPEED
Recommended Cutting 5 mph (8 km/hr)
* 50–85 rpm for M100, M105.
NOTE: 1. Specifications and design are subject to change without notice or obligation to revise previously sold units.
