SECTION 5 SPECIFICATIONS
169000 / 169040
21
Revision E
5.2 SELF-PROPELLED HEADERS
HEADER SIZE 14 FT 16 FT 18 FT
HEADER MODEL A30-S A40-D A30-S A40-D A40-D
FRAME and STRUCTURE
Width 16 ft-3 in. (4953 mm) 17 ft-9 in. (5410 mm) 19 ft-3 in. (5867 mm)
Weight (lb [kg]) n/a 5680 (2579) n/a 5850 (2656) 6020 (2733)
Carrier MacDon M Series Self-Propelled Windrowers
Lighting Two Amber Transport Lights
Spare Knife Storage
Frame
Tube
Lean Bar
Frame
Tube
Lean Bar Lean Bar
Reversing Wrench/Guard Straightening Tool Stored Inside LH Endsheet
Manual Storage Windrower Cab
CUTTERBAR
Effective Cutting Width 14 ft-9 in. (4496 mm) 16 ft-3 in. (4953 mm) 17 ft-9 in. (5410 mm)
Cutting Height 5.9 in. (150 mm) Below Ground to 35.4 in. (900 mm) Above Ground
Guard Angle Adjustment 7–17.5°
HEADER DRIVE
A30 Hydraulic From Windrower Pump to One Piston Motor
A40 Hydraulic From Windrower Pump to One Piston Motor and Two Gear Motors
SICKLE
Belt Driven Heavy Duty (MD)
Sickle Drive Box (Enclosed Oil Bath)
Belt Type V Timing V Timing Timing
Quantity One Two One Two Two
Sickle Speed (Strokes Per Minute) 1540 1450–1950 1540 1450–1950 1450–1950
Stroke 3 in. (76 mm)
Sections Bolted Over-Serrated, 14 Serrations/Inch. (9 Serrations/Inch Optional)
Guards Forged And Double Heat-Treated
AUGER
Drive
Hydraulic Direct Mounted Motor --
15.9 in 3
(261 cc)
/rev
--
15.9 in 3
(261 cc)
/rev
15.9 in 3 (261 cc) /rev
Mechanical
2 Belts To
Chain
---
2 Belts To
Chain
--- ---
Max Speed (rpm)
20T Sprocket 260
230–320*
260
230–320* 230–320*
19T Sprocket Tube 250 250
Size
19T Sprocket Tube 10 in. (254 mm) O.D.
Flighting 20 in. (508 mm) O.D., 0.25 in. (6 mm) thick.
Type Undershot, Center Feed. Rubber Finger Feed
Stripper Bars 3 Per Side
Delivery Opening 95.7 in. (2430 mm)
* Maximum Speed on M100, M105 Windrower
