b) Detach the battery cover
Turn the locking screws (right and left) downwards and lift the battery cover
away from the PDT.
Figure 2-8: Detach the battery cover
c) Insert the battery pack
Insert the battery pack into the battery compartment with the label facing out.
Ensure that the battery snaps into place.
Figure 2-9: Insert the battery pack.
