Opticon PHL 8000 - Manual (Page 23)

Opticon
PHL 8000 series
User Manual
23
Table 2-8. PHL 8200 overview
Label Description
1 Scanner LED Indicator Red color: Reading barcode
Green color: Successful reading
2 Charge LED Indicator Red color: Charging battery
Green color: Battery fully charged
3 LCM / Touch Panel Do specific action through touch panel by stylus
4 Left Scan key
Right Scan key
Scan key Start scanning the barcode by pressing any one of
these three scan keys
5 Power key Puts the PDT into power mode and wakes the PDT
from suspend mode.
6 F1–F4 key The four application keys, hot keys of application
program defined by end user.
7 Navigation key Navigation keys for left, right, up and down directions
8 Alpha keys Alpha keys
9 Numeric keys Numeric keys
10 Fn key Used in combination with other keys to type special
characters and perform system functions.
11 Enter key Confirms data entry
12 Earphone jack connector A connector to plug a earphone
13 USB / serial /
synchronization port
A connector to support USB host/client and serial
functions
14 Scan window Barcode reader window
15 Stylus Use the stylus for selecting items and entering
information.
16 Battery cover Protects the battery pack and maintains the IP rating of
the PDT.
17 Battery cover latch Keeps battery cover locked
18 Hand strap Can be adjusted tighter or looser
19 Speaker 1 W speaker for audio sound
20 DC power jack A connector to support AC power.
21 IrDA A window to support IrDA functions
