SNAP-LOC 24
12
FASTENER SELECTION GUIDE
(CONT.)
STITCH
SIZE
1
/
4
-14 x
7
/
8
"
1
/
4
-14 x
7
/
8
"
1
/
4
-14 x
7
/
8
"
TYPE
Stitch
Stitch
Stitch
APPLICATION
Flashing to Panel
or Flashing
Flashing to Panel
or Flashing
FINISH
Painted
XL*
XL
(Painted)**
STITCH XL
*XL Fasteners are recommended for use with bare galvalume panels and accessories.
**Painted XL Fasteners are recommended for use with painted panels and accessories.
SIZE
14 x 1
5
/
8
"
15 x 4"
15 x 5"
15 x 6"
TYPE
Driller
Driller
Driller
Driller
APPLICATION
For use on attachment of
Panel Clip to wood framing
Panel Clip/Bearing Plate to
metal deck and rigid board
insulation assembly
FINISH
Black
Black
Black
Black
DEKFAST
SHOULDER SELF DRILLER
SIZE
12-14 x 1
1
/
4
"
TYPE
Driller
FINISH
Plated
APPLICATION
For use with Floating
Rake Angle to metal
substructure
SIZE
10 x 1"
TYPE
A
APPLICATION
For use with Panel
Clip attaching to
plywood deck
FINISH
Plated
PANCAKE HEAD WOODSCREW
