Configuring system bus (CAN)
Assignment of the control word
l
95
EDBCSXE040 EN 7.0
8.8
Assignment of the control word
Control word to the power supply module (display in C0130)
Byte
Bit
Name
Meaning
LOW
0
STE_TOGGLE
Toggle bit: Bit state change as a "sign of life" of the
control
1
STE_RESET
0:
1:
Reset fault message
Active fault message
2
STE_KSB
0:
1:
No short−circuit braking (KSB)
Carry out short−circuit braking (KSB)
3
STE_REGLERFREIGABE
0:
1:
X6/DO1 always LOW
X6/DO1 is HIGH if the power supply module is ready for
operation and the input X6/DI2 is HIGH.
4
Free
...
7
HIGH
8
Reserved
...
10
11
Free
...
15
