Configuring system bus (CAN)
Individual addressing
Display of the resulting identifiers
8
l
87 EDBCSXE040 EN 7.0
Save changes with C0003 = 1.
The settings are only accepted after carrying out one of the following actions:
ƒ Renewed switch−on of the 24 V low−voltage supply
ƒ Reset node via the bus system (by the network management (NMT))
ƒ Reset node with C0358 = 1
)
Note!
If reset node is executed via GDC, communication will be interrupted. You
therefore have to log in again manually or find the devices connected to the
bus once again (fieldbus scan).
Display of the resulting identifiers
C0355 is the display code for the resulting identifiers:
ƒ General addressing ( ^ 164):
Identifier (COB−ID) = basic identifier + adjustable node address (node ID)
ƒ Individual addressing ( ^ 86):
Identifier (COB−ID) = 384 + ID offset (C0354)
Parameter
C0355
Designation
CAN_IN/OUT identifier (COB−IDs)
Data type: INTEGER_32
Index: 24220
dec
= 5E9C
hex
Display of the CAN_IN/OUT identifiers (COB−IDs)
^ 87
Display range
(min. value | unit | max. value)
0 2047
Subcodes Information
C0355/1 COB−ID CAN1_IN
C0355/2 COB−ID CAN1_OUT
C0355/3 COB−ID CAN2_IN
C0355/4 COB−ID CAN2_OUT
C0355/5 COB−ID CAN3_IN
C0355/6 COB−ID CAN3_OUT
