Electrical installation
Power terminals
5
l
41 EDBCSXE040 EN 7.0
5.3 Power terminals
{
Danger!
Dangerous voltage
The leakage current to earth (PE) is > 3.5 mA AC or > 10 mA DC.
Possible consequences:
ƒ Death or severe injuries when the device is touched in the event of a fault.
Protective measures:
ƒ Implement the actions required in the EN 61800−5−1. Especially:
– Fixed installation
– PE connection must conform to standards (PE conductor diameter
³ 10 mm 2 or PE conductor must be connected twice)
(
Stop!
No device protection if the mains voltage is too high
The mains input is not internally fused.
Possible consequences:
ƒ Destruction of the device if the mains voltage is too high.
Protective measures:
ƒ Observe the maximally permissible mains voltage.
ƒ Fuse the device correctly on the supply side against mains fluctuations and
voltage peaks.
ƒ All power connections are plug connections and are coded. The connector set for the
ECSZE000X0B power supply modules must be ordered separately.
ƒ Installation of cables acc. to EN 60204−1.
ƒ The cables used must comply with the approvals required for the respective
application (e.g. VDE, UL, etc.).
Assignment of the plug connectors
Terminal Function Electrical data
X21 Mains connection
X21/L1 Mains phase L1 Dependent on application and type
0 ... 480 V
up to 31.3 A (
^ 22)
X21/L2 Mains phase L2
X21/L3 Mains phase L3
X21/PE Connection of PE conductor
X22 DC−bus voltage connection
X22/BR0 Internal brake resistor, connection 1 Dependent on application and type
0 ... 770 V
up to 38.5 A (
^ 22)
X22/BR1 External brake resistor, connection 1
X22/+UG Internal/external brake resistor, connection 2
X22/+UG DC−bus voltage supply, plus
X22/−UG DC−bus voltage supply, minus
X22/PE Connection of PE conductor
