Mechanical installation
Mounting with thermal separation (push−through technique)
Dimensions
4
l
29 EDBCSXE040 EN 7.0
4.3.1 Dimensions
)
Note!
Mounting with ECSZS000X0B shield mounting kit:
ƒ Mounting clearance below the module > 195 mm
Z
c1 c1
h h
a1
e e1 a
g
g
g
d b
g
a
d b
b1 b1
³
65
mm
³
65
mm
a1
Z
0 1
ECSXA007
Fig. 4−2 Dimensions for "push−through design"
Z Mounting cutout (a1 x b1), ^ 30
Power supply module Dimensions [mm]
Type Size a a1 b b1 c1 d e e1 g h
ECSDE012
0 88.5 78.5
240 197 75 250
109
145 1)
67 M5 10.5 ECSDE020
ECSDE040 1 131 121.5
1) max. 145 mm, depending on the communication module attached
