12 Implemented DeviceNet objects
12.6 Lenze Class (0x65 / 101)
74
Lenze · E94AYCDN communication module (DeviceNet™) · Communication Manual · DMS 5.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
12.6 Lenze Class (0x65 / 101)
This object contains some information regarding responses to communication faults.
 Interruption of the DeviceNet communication ( 39)
Instance 0
Instance 1
Services
Attribute Service(s) Designation Data type Value
1 GET Revision UINT 1 (0x01)
Attribute Service(s) Designation Data type Value
1 GET / SET Response to "Idle Mode" USINT Corresponds to the value in
C13880/1 / C14880/1 :
0 = no response
1 = error
3 = quick stop by trouble
4 = warning locked
6 = information
2 GET / SET Response to communication
errors
USINT Corresponds to the value in
C13880/3 / C14880/3 :
0 = no response
1 = error
3 = quick stop by trouble
4 = warning locked
6 = information
4 GET / SET Response to I/O timeout USINT Corresponds to the value in
C13880/2 / C14880/2 :
0 = no response
1 = error
3 = quick stop by trouble
4 = warning locked
6 = information

Note
The parameters of the "0x65" class are described in the EDS file and therefore can be set
directly in the properties dialog of the DeviceNet nodes under "Parameters" via the
»RSNetWorx« Rockwell software.
Service code Designation Description
0x0E Get_Attribute_Single Reading an attribute
0x10 Set_Attribute_Single Writing an attribute
