11 Parameter reference
11.2 Parameters of the communication module for the MXI1 slot
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13883
C13884
C13885
C13900
Parameter | Name:
C13883 | Data length of consumed I/O data
Data type: UNSIGNED_8
Index: 10692 = 0x29C4
Setting of the data length (in bytes) of the I/O data received by the device via DeviceNet.
Note:
• If the data length is changed, the DeviceNet scanner will be informed about this change (consumed data size).
• If the data length is reduced, it must be checked before whether the intended data length is sufficient for the
application.
• If the data length of the consumed I/O data does not correspond to the length of the mapped ports which is
specified by the drive via PDO mapping, the DeviceNet: Consumed I/O data length is contradictory [0x00C88211]
( 46) error message is generated and entered as a warning into the logbook of the standard device.
• If the number of consumed I/O data deviates from the Lenze setting (4 bytes), the "Automap on Add" function in
the scanner configuration dialog of the »RSNetWorx« software has to be deactivated and the number of the
process data words has to be adapted via the "Edit I/O parameters" button.
Setting range (min. value | unit | max. value) Lenze setting
0 64 4
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13884 | Data length of produced I/O data
Data type: UNSIGNED_8
Index: 10691 = 0x29C3
Setting of the data length (in bytes) of the I/O data to be transmitted by the device via DeviceNet.
Note:
• If the data length is changed, the DeviceNet scanner will be informed about this change (produced data size).
• If the data length is reduced, it must be checked before if the intended data length is sufficient for the
application.
• If the data length of the produced I/O data does not correspond to the length of the mapped ports which is
specified by the drive via PDO mapping, the DeviceNet: Produced I/O data length is contradictory [0x00C88212]
( 46) error message is generated and entered as a warning into the logbook of the standard device.
• If the number of produced I/O data deviates from the Lenze setting (4 bytes), the "Automap on Add" function in
the scanner configuration dialog of the »RSNetWorx« software has to be deactivated and the number of the
process data words has to be adapted via the "Edit I/O parameters" button.
Setting range
(min. value | unit | max. value)
Lenze setting
0 64 4
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13885 | Delete process data
Data type: UNSIGNED_8
Index: 10690 = 0x29C2
Setting of the process data which must be further processed by the drive to maintain internal communication if the
current network status ( C13862 ) is "Minor Fault" or "Critical Link Failure".
Selection list (Lenze setting printed in bold)
0 Use of the latest scanner I/O data
1 I/O data are set to a value of '0'
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13900 | Firmware: Product type
Data type: VISIBLE_STRING
Index: 10675 = 0x29B3
Display of the product type (string with a length of 8 bytes)
The following identification code will be output: "E94AFCDN"
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
