10 Error messages
10.3 DeviceNet error messages
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
10.3 DeviceNet error messages
Code
[hex]
Error designation Description
0x00 SUCCESS No fault
0x02 RESOURCE UNAVAILABLE Resource required to perform the service not available.
0x03 INVALID PARAM VALUE Invalid parameter value
0x08 SERVICE NOT SUPP Service is not supported.
0x09 INVALID ATTRIB VALUE Invalid attribute.
0x0B ALREADY IN STATE The object is already in the required state.
0x0C OBJ STATE CONFLICT The object cannot perform the service.
0x0E ATTR NOT SETTABLE The attribute is write-protected.
0x0F PRIVILEGE VIOLATION Access denied.
0x10 DEVICE STATE CONFLICT The current state of the device prohibits performing the
requested service.
0x11 REPLY DATA TOO LARGE The response data are longer than the response buffer
0x13 NOT ENOUGH DATA The data length is too short.
0x14 ATTRIBUTE NOT SUPP The attribute is not supported.
0x15 TOO MUCH DATA The data length is too long.
0x16 OBJECT DOES NOT EXIST The device does not support the object.
0x17 FRAGMENTATION The fragmentation for the requested service is currently not
activated.
0x20 INVALID PARAMETER Invalid parameter
