11 Parameter reference
11.2 Parameters of the communication module for the MXI1 slot
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13789
C13850
C13851
Parameter | Name:
C13789 | Service code
Data type: UNSIGNED_8
Index: 10786 = 0x2A22
This code is ...
• used device-internally and may not be written by the user.
• only displayed from »Engineer« version 2.9.
Setting range (min. value | unit | max. value)
0 32
Subcodes Lenze setting Info
C13789/1 0 Service code
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13850 | All words to scanner
Data type: UNSIGNED_16
Index: 10725 = 0x29E5
Display of the process data words transferred from the communication module to the scanner.
In the subcodes 1 to 32, all process data words to the scanner are displayed. However, only the configured process
data words are valid.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C13850/1
...
C13850/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13851 | All words from scanner
Data type: UNSIGNED_16
Index: 10724 = 0x29E4
Display of the process data words transferred from the scanner to the communication module.
In the subcodes 1 to 32, all process data words from the scanner are displayed. However, only the configured process
data words are valid.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C13851/1
...
C13851/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
