Kinze 3200 Wing-Fold Planter Rev. 5/14 - Manual (Page 99)

ITEM PART NO. QTY. DESCRIPTION
1 G10064
G11385
G10110 8
8
8 Hex Head Cap Screw, ¼"-20 x 1"
Flat Washer, ¼" SAE
Lock Nut, ¼"-20, Grade B
2 GA6701
GR1956
GR1208 2
-
-
Single Amber Light Assembly
Amber Lens Kit, Includes: (1) Amber Lens, (1) Gasket, and (3) Hex Head Cap Screws
Bulb
3 GA6824
GA6823 -
1
Bracket, R.H.
Bracket, L.H. (Shown)
4 GA6699
GA6700
GR1956
GR1957
GR1958
GR1208 1
1
-
-
-
-
Double Light Assembly
Double Light Assembly (Shown)
Amber Lens Kit, Includes: (1) Amber Lens, (1) Gasket, and (3) Hex Head Cap Screws
Red Lens Kit, Includes: (1) Red Lens, (1) Gasket, and (3) Hex Head Cap Screws
Black Cover Kit, Includes: (1) Black Cover, (1) Gasket, and (3) Hex Head Cap Screws
Bulb
5 G10017
G10228
G10102 4
4
4 Hex Head Cap Screw, ½"-13 x 1½"
Lock Washer, ½"
Hex Nut, ½"-13
6 GD11285 2 Angle
7 G10003
G10229
G10101 4
4
4 Hex Head Cap Screw, ⅜"-16 x 1½"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
8 GD7145
G10228
G10102 2-4
4-8
4-8 U-Bolt, 7" x 7" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
9 G11385
G10110
G10023 4
4
4 Flat Washer, ¼" SAE
Lock Nut, ¼"-20, Grade B
Hex Head Cap Screw, ¼"-20 x ¾"
10 GA9207
GA5385 -
- Wiring Harness W/7 Terminal Female Connector, 329" (4 Light Connections)
7 Terminal Female Connector
11 G1K248 - 3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
12 G1K252 - 3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
13 GD11089 - Sealing Plug
14 GA8047 - Dust Plug (Black)
15 GA9209 2 Light Bracket
16 G1K321 - 2-Pin Female Connector Kit (Black), Includes: (3) 2-Pin Female Housings, (6) Pin
Contacts, (6) Seals
17 G1K320 - 2-Pin Male Connector Kit (Black), Includes: (3) 2-Pin Male Housings, (6) Socket
Contacts, (6) Seals
Electrical Components
TM
Model 3200 M0241-02
6/11 P96
