ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 --- - See “Seed Rate Transmission Assembly and Driveline” on page P79
2 G10496 2 External Inverted Snap Ring, 1½"
3 G10253
G10257 3
3 Hex Socket Head Screw, No. 10-32 x ½"
Lock Washer, No. 10
4 GD9667 1 Bushing
5 GD10103 1 Mounting Plate
6 G10859 1 Spring Pin, 3∕16" x 2¼"
7 G10325
G11387
G10101 1
2
2 Hex Head Cap Screw, ⅜"-16 x 2¾"
Flat Washer, ⅜" SAE
Hex Nut, ⅜"-16
8 GD11120 1 Rue Ring Cotter, 5∕16"
9 GD10510 1 Actuator Arm
10 G10049
G10101
G11387
G10229
G10497 1
1
1
2
1 Hex Head Cap Screw, ⅜"-16 x 2½"
Hex Nut, ⅜"-16
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Jam Nut, ⅜"-16, Grade 2
11 GD10123 1 Spring
12 GD10104 1 Input Hub
13 GD10525 1 Sprocket, 34 Tooth
14 GD10200 1 Sleeve, ¾" Long
15 G10023
G10227 3
3 Hex Head Cap Screw, ¼"-20 x ¾"
Lock Washer, ¼"
16 GD14512 2 V-Ring Seal
17 GD14513 1 Felt Washer
18 GA7137
G10804
G10765 1
-
-
Hub/Sleeve Assembly W/Spring Pins
Spring Pin, 5∕32" x ⅞"
Spring Pin, ¼" x 1"
19 GD9672
GD9671 1
-
Spring, R.H.
Spring, L.H.
20 GD10102 1 Stop Collar
21 G10900
G10227
G10103 1
1
2 Hex Socket Head Cap Screw, ¼"-20 x 1¾", Grade 8
Lock Washer, ¼"
Hex Nut, ¼"-20
22 G10023
G10227
G10103 1
1
1 Hex Head Cap Screw, ¼"-20 x ¾"
Lock Washer, ¼"
Hex Nut, ¼"-20
23 GA8393
GR1306
GR1303
GR1304
GR1305 1
1
1
1
1 Solenoid Complete
Snap Ring
Spring
Boot
Plunger
24 GD10528
GD10529 -
1
Bracket, R.H. (Shown)
Bracket, L.H.
25 GD7145
G10111 1
2 U-Bolt, 7" x 7" x ½"-13
Lock Nut, ½"-13
26 GA10054 1 Ground Cable, Green
A GA7418 - Point Row Clutch Assembly, R.H. (R.H. Side Of Machine) (Items 2-6, 8-13, 15-23, And 26)
B GA7417 - Point Row Clutch Assembly, L.H. (L.H. Side Of Machine) (Items 2-6, 8-13, 15-23, And 26)
Point Row Clutch
TM
Model 3200 M0241-02
6/11 P68
