Kinze 3200 Wing-Fold Planter Rev. 5/14 - Manual (Page 111)

Planter Monitor Module (PMM)
ITEM PART NO. QTY. DESCRIPTION
1 G10686
G11091 4
4 Hex Head Cap Screw, ⅜"-16 x 8"
Serrated Flange Nut, ⅜"-16
2 GD18118 2 Shaft Sensor Mount
3 GR1415 1 Rotation Sensor
4 GR1414 1 Actuator
5 GD18168 2 Mount
6 G11288
G10243
G10758 2
2
2 Pan Head Screw, No. 10-32 x 1½"
Washer, No. 10 SAE
Hex Nut, No. 10-32
7 GD11474 2 Cover
8 G10927
G10931
G10928 2
2
2 Pan Head Machine Screw, No. 8-32 x 1¼", Stainless Steel
Lock Washer, No. 8, Internal/External, Stainless Steel
Hex Nut, No. 8-32, Stainless Steel
9 GA5600 1 Magnetic Distance Sensor
10 GD8751 - Magnetic Distance Sensor Pulse Wheel
11 GD6291 - Insulated Clamp, ⅜"
12 G10001
G10229
G10101 2
2
2 Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
13 GD8770 1 Bracket
14 GD8771 1 Spring Wave Washer
15 GA7852
GD11993 -
- Planter Harness W/Dust Caps, 12 Row (20 Connectors)
Dust Cap
16 GA15287
GA18919 -
- Seed Tube W/Computerized Sensor
Seed Tube
17 GA7859 - Magnetic Distance Sensor Adapter (Analog To Digital)
18 G1K248
G1K362
-
-
3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
3-Pin Female Connector Kit (Blue), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
19 G1K252
G1K363
-
-
3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
3-Pin Male Connector Kit (Blue), Includes: (3) 3-Pin Male Housings, (9) Socket Con-
tacts, (9) Seals
20 GD11089 - Sealing Plug
21 GR0594 - Brush
22 GA8047
GA9979 -
- Dust Plug (Black)
Dust Plug (Blue)
23 GA8046
GA9978 -
- Dust Plug (Black)
Dust Plug (Blue)
24 GD16598
G11415 2
4 U-Bolt, 4" x 7" x ⅝''-11
Serrated Flange Nut, ⅝"-11
25 GD19759 2 Module Bracket Mount
26 GD18013 1 Bracket
27 G10171
G10620 4
4 Hex Head Cap Screw, 5⁄16"-18 x 1¼"
Serrated Flange Nut, 5⁄16"-18
28 --- - See “Ag Leader Electric Clutch Package” on page P111
See “ISOBUS Electric Clutch Package” on page P109
29 G10019
G10620 2
2 Hex Head Cap Screw, 5⁄16"-18 x 1"
Serrated Flange Nut, 5⁄16"-18
30 GA12563 1
31 GA7854
GD11993 1
-
Extension Harness W/Dust Cap, 15'
Dust Cap
32 GA16923 - Dickey John Adapter Cable
A GA6147 - Magnetic Distance Sensor And Mounting Package (Items 9-14)
TM
Model 3200 M0241-02
Rev. 5/14 P108
