Kinze 3200 Wing-Fold Planter Rev. 5/14 - Manual (Page 67)

Contact Wheel and Arm Assembly
ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
11 G10478
G10409 1
1
Clevis Pin, 5∕16" x 1"
Retaining Ring, 5∕16"
12 G10017
G10128
G10501 1
1
1
Hex Head Cap Screw, ½"-13 x 1½"
Machine Bushing, ½", 14 Gauge
Hex Jam Nut, ½"-13, Grade 2
13 GA9553
GA9554
GA7154
G10017
G10128
G10501 1
1
-
-
-
-
Idler W/Sprocket And Hardware, L.H.
Idler W/Sprocket And Hardware, R.H. (Shown)
Sprocket W/Bearing, 18 Tooth
Hex Head Cap Screw, ½"-13 x 1½"
Machine Bushing, ½", 14 Gauge
Hex Jam Nut, ½"-13, Grade 2
14 G10013
G10036
G11391
G10107
G10104 1
1
1
1
1
Hex Head Cap Screw, ⅝"-11 x 3½"
Hex Head Cap Screw, ⅝"-11 x 4"
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-11
Hex Nut, ⅝"-11
15 G10303
G10232
G10106 -
-
-
Carriage Bolt, 5∕16"-18 x 1"
Lock Washer, 5∕16"
Hex Nut, 5∕16"-18
16 GD5857 1 Spring
17 GA5202 1 Sprocket, 34 Tooth
See “Point Row Clutch” on page P67 (If Applicable)
18 G10130
G10923 1
1
Square Head Machine Bolt, 5∕16"-18 x 1¾"
Flange Nut, 5∕16"-18, No Serration
19 --- - See “Seed Rate Transmission Assembly and Driveline” on page P79
20 GD11045 1 Lock Clamp
21 G3310-74
GR0912
1
-
Chain, No. 40, 74 Pitch Including Connector Link, See “Two-Speed Point Row Clutch
Drive” on page P75 (If Applicable)
Connector Link, No. 40
22 --- - See “Transport and Ground Drive Wheel Assembly (Prior to 2012 Production)” on
page P59 or See “Transport and Ground Drive Wheel Assembly (2012 Production
and on)” on page P61
23 GA8041 1 Wheel Tower
24 G10055
G10107 2
2
Hex Head Cap Screw, ⅝"-11 x 1¼" (Stop Bolt)
Lock Nut, ⅝"-11
25 GA2068 2 Spring W/Plug
26 G10501 2 Hex Jam Nut, ½"-13, Grade 2
27 GA8042 1 Arm
28 G10890 2 Hex Head Adjusting Bolt, ½"-13 x 4", Grade 2
29 GD11157 2 Spacer, 1½" O.D. x ⅝" Long
30 GA5090
GD5753
GD5752
GA5089 1
-
-
-
Tire And Rim Assembly (Specify Brand*)
Tire, 4.10" x 6" (Specify Brand*)
Inner Tube
Rim, 3.25" x 6"
(Sub GA5090)
31 GA9846 - Flanged Bearing, ⅞" Hex Bore
32 GD6825-11.625 1 Hex Shaft, ⅞" x 11⅝" (2 Holes)
33 G3310-91
G3310-102
G3310-104
GR0912
---
1
-
-
-
-
Chain, No. 40, 91 Pitch Including Connector Link and Offset Link, Used With 15 And
19 Tooth Sprockets (EdgeVac)
Chain, No. 40, 102 Pitch including Connector Link (Mechanical)
Chain, No. 40, 104 Pitch Including Connector Link, Used With 38 Tooth Sprocket
Connector Link, No. 40
See “Two-Speed Point Row Clutch Drive” on page P75 (If Applicable)
34 GA5105
GA5107
GA11285
GA5114
--- 1
-
-
-
-
Sprocket, 15 Tooth (EdgeVac or Half Rate (2 to 1) Drive)
Sprocket, 19 Tooth (EdgeVac)
Sprocket, 38 Tooth (EdgeVac)
Sprocket, 30 Tooth (Mechanical)
See “Two-Speed Point Row Clutch Drive” on page P75 (If Applicable)
TM
Model 3200 M0241-02
6/11 P64
