Kinze 3200 Wing-Fold Planter Rev. 5/14 - Manual (Page 108)

ITEM PART NO. QTY. DESCRIPTION
34 8647x
GA12403
GR1762
GA16082
1
-
-
-
KPM III Backlit Console W/Brush (Item 28), Dust Plug (Item 36), Mounting
Bracket Assembly, Console Mounting Bracket Hardware And Power Harness
Mounting Bracket Assembly, Includes: (2)Mounting Brackets, (2) Connector
Halves, (1) Compression Spring, (1) Tension Knob, (1) ¼"-20 x 1 ¾" Hex
Head Cap Screw, (1) ¼" Plastic Washer, (1) ¼" Steel Washer
Console Mounting Bracket Hardware Package, Includes: (3) No. 10-32 x ⅝"
Hex Socket Pan Head Plated Screws, (3) No. 10 Plated Lock Washers
Power Harness
35 G1K249 - Acre Counter Switch Kit
36 GA8046
GA9978 -
- Dust Plug (Black)
Dust Plug (Blue)
37 GA8047
GA9979 -
- Dust Plug (Black)
Dust Plug (Blue)
38 G1K321 - 2-Pin Female Connector Kit (Black), Includes: (3) 2-Pin Female Housings, (6) Pin
Contacts, (6) Seals
39 G1K320 - 2-Pin Male Connector Kit (Black), Includes: (3) 2-Pin Male Housings, (6) Socket
Contacts, (6) Seals
40 G1K248 - 3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
G1K362 - 3-Pin Female Connector Kit (Blue), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
41 G10686
G10229
G10101 4
4
4 Hex Head Cap Screw, ⅜"-16 x 8"
Lock Washer, ⅜"
Hex Nut, 3/8"-16
42 GD18118 2 Shaft Sensor Mount
43 GD18168 2 Mount
A GA6147 - Magnetic Distance Sensor And Mounting Package (Items 13-17 And 21)
B GR1763 - KPM III Loaner Display Only
C GA13521 - Shaft Sensor Mounting (Items 3, 4, 8, and 41-43)
KPM III Electronic Seed Monitor
M0241-02 Model 3200
P105 Rev. 7/12
TM
