Kinze 3200 Wing-Fold Planter Rev. 5/14 - Manual (Page 135)

ITEM PART NO. QTY. DESCRIPTION
1 G4301-06 1 Hose, ⅜" x 160'
2 G10681 24 Hose Clamp, No. 6
3 GD11700 12 Adapter, ¼" NPT To ⅜" Barb
4 --- - See “Liquid Fertilizer Piston Pump Flow Divider” on page P133
5 G10292 - Pipe Plug, ¼" NPT
6 G10995 1 Reducing Bushing, 1" Male NPT To ¾" Female, Stainless Steel
7 G10994 1 Close Nipple, ¾" NPT, Stainless Steel
8 --- - See “Liquid Fertilizer Piston Pump (Cylinder Assembly) Uses 18 Tooth Sprocket” on
page P137
9 --- - See “Liquid Fertilizer Piston Pump (Crankcase Assembly) Uses 18 Tooth Sprocket”
on page P135
10 --- - See “Liquid Fertilizer Piston Pump Drive” on page P127
11 G10615 1 Reducing Bushing, 1½" Male NPT To 1¼" Female
12 G10629 2 Elbow, 90°, 1¼" NPT To Barb,
13 --- - See “Liquid Fertilizer Tanks, Saddles, Saddle Mounts, and Hoses” on page P125
14 G10626 1 Adapter, 1¼" NPT To Barb
15 GA3893
GR0880
GR0881
GR0882
GR0883 1
-
-
-
-
Strainer Complete
Screen, No. 40 Mesh
Gasket
Y-Body
End Cap
16 G10619 1 Close Nipple, 1¼" NPT
17 GA4976
GR1015
GR1016
GR1017
GR1018
GR1019 2
-
-
-
-
-
Shutoff Valve, 1¼" NPT
Body O-Ring
Stem O-Ring
Teflon Seal
Ball
Handle
18 GA6527 1 Mount, ¾" NPT
19 GD1114
G10230
G10104 1
2
2 U-Bolt, 7" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
20 G10733 1 Elbow, 90°, ¾" Female NPT
21 G10734 1 Adapter, ¾" NPT To Barb
22 G10278 2 Hose Clamp, No. 16
23 G4205-04 - Hose, ¾" x 36"
24 G10917 1 Elbow, 90°, ¾" NPT To Barb
25 G11237 1 Reducing Bushing, 1½" Male NPT To ¾" Female
26 --- - See “Liquid Fertilizer Piston Pump”, Pages P100 And P101
Liquid Fertilizer Flow Divider Mount and Hoses
TM
Model 3200 M0241-02
6/11 P132
