Kinze 3200 Wing-Fold Planter Rev. 5/14 - Manual (Page 7)

Parallel Arms, Mounting Support Plate, and Quick Adjustable
Down Force Springs
ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 GD1114
G10230
G10104 2
4
4 U-Bolt, 7" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
2 GD10036 1 Mounting Support Plate
3 GB0218 8 Bushing, 21∕32" I.D. x ⅞" O.D. x 19∕32" Long
4 GD11422 2 Upper Parallel Arm
5 G11391 8 Flat Washer, ⅝" SAE
6 G10732
G11514 4
4 Hex Head Cap Screw, ⅝"-18 x 2"
Lock Nut, ⅝"-18
7 GB0186 2 Spring Anchor
8 GD14217 2 Tab Lock Pin, 7∕16" x 1½"
9 GD8249
GD21337 4 Standard Spring
Heavy Duty Down Pressure Spring
10 G10752
G11514 2
2 Hex Head Cap Screw, ⅝"-18 x 2¼"
Lock Nut, ⅝"-18
11 GA5651 1 Lower Parallel Arm
12 G10751
G11514 2
2 Hex Head Cap Screw, ⅝"-18 x 1¾"
Lock Nut, ⅝"-18
13 GA1720 1 Bearing/Sprocket, ⅞" Hex Bore
14 G10004
G11091 2
2 Hex Head Cap Screw, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
15 GA8140
G10230
G10104 -
-
- T-Bolt, ⅝"-11 x 7"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
16 --- - ---
17 GA16830
GA16868
GD24352
GD24126
G11491
G10110
G11385
G10023 1
1
1
1
2
2
2
2 Sensor
Implement Switch Adapter Cable
Sensor Bracket
Implement Switch Bracket, Long
Washer
Lock Nut, ¼"-20, Grade B
Flat Washer, ¼" SAE
Hex Head Cap Screw, ¼"-20 x ¾"
A G6326X - U-Bolt Package For 7" x 7" Toolbar, Includes: (2) GD1114, (4) G10230, (4)
G10104
B G1K528 - Implement Switch Kit, Includes: (1)A16868, (1)A16829, and (1)IS826
TM
Model 3200 M0241-02
Rev. 5/13 P4
